Gigabyte B660M GAMING X AX DDR4 12th Gen Micro ATX Motherboard

-4 %

Gigabyte B660M GAMING X AX DDR4 12th Gen Micro ATX Motherboard

Offer Price: 19,100৳
Price: 19,800৳
Stock: In Stock
Brand: Gigabyte
Model: B660M GAMING X AX DDR4
Product Code: 845381

Based on 0 reviews. - Write a review

19,100৳

19,800৳

Ex Tax: 19,100৳

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

LGA1700 socket support 12th Gen Intel Series Processors
Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMsâ€‹
8+1+1 Hybrid Digital VRM Design with DrMOS
WIFI 6 802.11ax 2T2R & BT5 with AERO Antenna

View more details

For further queries, please call 01958-013555

Specification

Basic Information
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Supported CPU	Support for 12th/ 13th/ 14th Generation Intel Core i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1700 package L3 cache varies with CPU
Chipset	Intel B660 Express Chipset
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Expansion Slots
PCI	1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 4.0 standard.) 1 x PCI Express x16 slot, running at x4 (PCIEX4) (The PCIEX4 slot conforms to PCI Express 3.0 standard.)
Memory Specifications
Maximum Memory	Up to 128 GB (32 GB single DIMM capacity)
Slots	4 x DIMM
Supported Memory	Support for DDR4 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /3200/ 3000/ 2933/ 2666/ 2400/ 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Type	DDR4
Graphics Specifications
Graphics	Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
Connector & Ports
Audio	3 x audio jacks
Display Port	1 x DisplayPort
HDMI	1 x HDMI 2.1 port
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x S/PDIF Out header 2 x Thunderbolt add-in card connectors 1 x serial port header 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper
LAN Port (s)	2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Intel Optane Memory Ready
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
USB (s)	Chipset: 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 1 x USB 2.0/1.1 port on the back panel Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Wireless Communication module	Intel Wi-Fi 6 AX200 (For PCB rev. 1.0) WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band BLUETOOTH 5.2 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Intel Wi-Fi 6E AX211 (For PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.2 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Others
Special Features	Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install
Warranty Information
Manufacturing Warranty	3 years

Description

Gigabyte B660M GAMING X AX DDR4 12th Gen Micro ATX Motherboard

The Gigabyte B660M GAMING X AX DDR4 Micro ATX Motherboard is a powerful and affordable choice for gamers and PC builders in Bangladesh. Designed to support 12th and 13th Gen Intel Core processors, it offers next-gen connectivity, advanced thermal design, and fast wireless performance. With Intel Wi-Fi 6 / Wi-Fi 6E (depending on PCB revision) and Bluetooth 5.2, users can enjoy smoother online gaming and streaming. Featuring 4 x DDR4 DIMM slots, PCIe 4.0 support, Q-Flash Plus, LAN bandwidth management, and long-lasting build quality — it’s a complete solution for performance-driven builds.

If you're looking for a reliable gaming motherboard with advanced features and strong durability, this model delivers excellent value — especially for those comparing Gigabyte B660M Gaming X AX DDR4 price in Dhaka and Bangladesh.

Key Features

Supports Intel 12th & 13th Gen CPUs with LGA1700 socket
Intel B660 Express Chipset for smooth system performance
Dual-band Wi-Fi 6 / Wi-Fi 6E (AX200 for rev 1.0, AX211 for rev 1.1)
Bluetooth 5.2 connectivity for wireless accessories
Up to 2.4 Gbps high-speed wireless networking
4 x DDR4 RAM slots — Up to high-capacity memory support
PCIe 4.0 graphics support for improved GPU performance
DisplayPort output — Supports integrated Intel graphics
Q-Flash Plus — Update BIOS easily without CPU or GPU
3-year official warranty in Bangladesh
includes LAN bandwidth management and Norton Internet Security (OEM)

FAQs

Q1: What processors are compatible with this board?

It supports Intel 12th & 13th Gen Core, Pentium Gold, and Celeron processors using LGA1700.

Q2: Does this motherboard support DDR5 RAM?

No, this model supports DDR4 memory only.

Q3: Is Wi-Fi built-in or separate?

It comes with built-in Intel Wi-Fi (AX200 or AX211 depending on PCB version).

Q4: Is this good for gaming?

Yes! With PCIe 4.0 support, fast wireless, and strong VRM design — great for mid to high-tier gaming builds.

Q5: What is the Gigabyte B660M GAMING X AX DDR4 price in Bangladesh?

Prices can vary depending on store and availability — for the latest deals, check trusted PC retailers in Dhaka and across Bangladesh.

Q6: Does it support future upgrades?

Yes! You can upgrade to 13th Gen Intel CPUs and higher-end GPUs while keeping DDR4 for cost savings.
