GIGABYTE Z890 UD WIFI6E ATX Motherboard

Offer Price: 33,500৳
Price: 34,500৳
Stock: In Stock
Brand: Gigabyte
Model: Z890 UD WIFI6E
Product Code: 845973

Based on 0 reviews. - Write a review

33,500৳

34,500৳

Ex Tax: 33,500৳

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supported CPU: Intel Core Ultra Processors (Series 2), LGA1851 socket
Supported RAM: 4x DDR5, Max 256GB, Supports Up to 9200 (O.C)
Graphics Output: 1x USB4 USB Type-C, 1x DisplayPort
Features: 3x M.2 slots, Wi-Fi 6E, Bluetooth 5.3

View more details

For further queries, please call 01958-013555

Specification

Basic Information
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Supported CPU	Support for Intel Core Ultra Processors L3 cache varies with CPU
Chipset	Intel® Z890 Express Chipset
Expansion Slots
M.2 Socket	CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
Memory Specifications
Slots	4
Supported Memory	256GB
Type	DDR5
Graphics Specifications
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: - 1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 2.1 version - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 2.1 version (Graphics specifications may vary depending on CPU support.)
Connector & Ports
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x power button 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper
LAN Port (s)	Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
USB (s)	CPU: - 1 x USB4® USB Type-C® port on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel - 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: - 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Others
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Manufacturing Warranty	3 years

Description

GIGABYTE Z890 UD WIFI6E ATX Motherboard

The GIGABYTE Z890 UD WIFI6E ATX Motherboard is a next-generation performance motherboard designed for Intel Core Ultra processors. Powered by the advanced Intel Z890 Express Chipset, it delivers exceptional speed, improved power efficiency, and cutting-edge connectivity for gamers and professionals in Bangladesh.

With DDR5 memory support up to 256GB, PCIe 5.0 compatibility for future GPUs, and multiple high-speed M.2 slots, this board ensures fast application loading and extreme multitasking capabilities. Its integrated Wi-Fi 6E and 2.5GbE LAN offer ultra-stable network speeds — perfect for competitive gaming and 4K streaming.

Built with solid power phases, enhanced thermal design, and premium components, the GIGABYTE Z890 UD WIFI6E is the ideal foundation for future-proof PC builds in Dhaka and across Bangladesh.

Key Features

CPU Support Intel Core Ultra & 15th Gen LGA1851 Processors
Chipset Intel® Z890 Express
Memory DDR5 up to 256GB, Dual-Channel
Graphics Support PCIe 5.0 x16 Slot for High-End GPUs
Storage Multiple PCIe 4.0 M.2 Slots
Networking Built-in Wi-Fi 6E + 2.5GbE LAN
USB Support Latest Gen USB including Type-C High-Speed Ports
Cooling Large Heatsinks + Smart Fan Optimization
Audio Quality High-Definition Audio with Noise Guard
Durability PCIe Ultra-Durable Protection & Solid Power Design

FAQs

Q1: Does the Z890 UD WIFI6E support Intel Core Ultra processors?

Yes, it is fully designed for the latest Core Ultra series.

Q2: Does it support DDR5 RAM?

Yes — up to 256GB DDR5 for improved speed and multitasking.

Q3: Is Wi-Fi included?

Yes — built-in Wi-Fi 6E for ultra-fast wireless.

Q4: Does it support PCIe 5.0 graphics cards?

Yes — perfect for next-gen GPUs.

Q5: What is the GIGABYTE Z890 UD WIFI6E price in Bangladesh?

Pricing varies by retailer — I can help you check the latest price in Dhaka if you want.
