MSI H510M PRO Intel 10th & 11th Gen Mirco-ATX Gaming Motherboard

-1 %

MSI H510M PRO Intel 10th & 11th Gen Mirco-ATX Gaming Motherboard

Offer Price: 9,300৳
Price: 9,440৳
Stock: In Stock
Brand: MSI
Model: MSI H510M PRO
Product Code: 844604

Based on 0 reviews. - Write a review

9,300৳

9,440৳

Ex Tax: 9,300৳

Qty

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Model: H510M PRO
Supports 10th Gen Intel Core, 11th Gen,
DDR4 Memory, up to 3200(Max) MHz
LGA 1200 socket
PCIe 4.0, Turbo M.2

View more details

For further queries, please call 01958-013555

Specification

Basic Information
Form Factor	mATX Form Factor
Supported CPU	Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors1
Chipset	Intel H510 Chipset
Audio	7.1-Channel High Definition Audio
Expansion Slots
M.2 Socket	1x M.2 slot with E key for WiFi module only(M2_2)
PCI	1x PCIe x16 slot (From CPU) - Support up to PCIe 4.0 for 11th Gen Intel CPU - Support up to PCIe 3.0 for 10th Gen Intel CPU 1x PCIe 3.0 x1 slot (From PCH)
Memory Specifications
Maximum Memory	support up to 64GB
Slots	2x DDR4 memory slots
Supported Memory	Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP)
Type	DDR4
Graphics Specifications
Graphics	1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
Connector & Ports
Internal I/O Ports	1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 1x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 1x Clear CMOS jumper
LAN Port (s)	1x Intel I219V 1Gbps LAN controller
Supported Storage	4x SATA 6Gb/s ports (From H510 Chipset) 1x M.2 slot (Key M) - M2_1 slot (From H510 Chipset) - Supports up to PCIe 3.0 x4 - Supports SATA 6Gb/s1 - Supports 2242/ 2260/ 2280 storage devices
TPM (Trusted Platform Module )	1x TPM module connector
USB (s)	- 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector) - 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector)
Warranty Information
Manufacturing Warranty	03 years warranty

Description

MSI H510M PRO Intel 10th & 11th Gen Micro-ATX Motherboard

The MSI H510M PRO Micro-ATX Motherboard is built to provide dependable performance for home, office, and budget gaming PC builds in Bangladesh. Supporting Intel 10th and 11th Gen Core, Pentium Gold, and Celeron processors with the LGA1200 socket, it offers stable power delivery and efficient productivity.

This motherboard features DDR4 memory support, PCIe slots for graphics upgrades, and M.2 NVMe SSD compatibility for faster boot times. With HDMI, DisplayPort, and VGA video output, it supports multiple display setups for a better workflow.

Reliable, durable, and affordable — the MSI H510M PRO price in Bangladesh makes it a great choice for entry-level to mid-range PCs in Dhaka and across the country.

Key Features

Chipset: Intel H510
Memory: DDR4 Dual Channel up to 64GB
Graphics Outputs: HDMI 2.0b, DisplayPort 1.4 & VGA
Expansion Slots: PCIe 4.0 x16 (11th Gen CPU required) + PCIe x1
Storage Support: M.2 PCIe + 4x SATA III 6Gb/s ports
Networking: Intel LAN for stable wired connectivity
Form Factor: Micro-ATX — fits most budget-friendly cases
Protection; Military-grade components & surge protection

FAQs

Q1: What is the MSI H510M PRO price in Bangladesh?

A: Pricing varies by retailer. Check popular PC shops in Dhaka and leading online IT stores for the latest offers.

Q2: Is this motherboard good for gaming?

A: Yes — when paired with a compatible GPU, it handles popular esports and mid-range games smoothly.

Q3: Can I install an M.2 SSD?

A: Yes! It supports fast NVMe M.2 storage.

Q4: Does it support Wi-Fi?

A: The board does not include built-in Wi-Fi, but you can add a USB or PCIe Wi-Fi adapter.

Q5: How many monitors can it support?

A: It supports multiple display outputs with HDMI + DP + VGA.
