MSI MAG B650M MORTAR WIFI AM5 M-ATX Motherboard

-7 %

MSI MAG B650M MORTAR WIFI AM5 M-ATX Motherboard

Offer Price: 28,500৳
Price: 30,500৳
Stock: In Stock
Brand: MSI
Model: MAG B650M MORTAR MAX WIFI
Product Code: 813857

Based on 0 reviews. - Write a review

28,500৳

30,500৳

Ex Tax: 28,500৳

Qty

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supported CPU: Ryzen 7000 Series Processors for Socket AM5
Supported RAM: 4x DDR5, up to 6400+(OC) MHz

View more details

For further queries, please call 01958-013555

Specification

Basic Information
Form Factor	mATX 243.84mmx243.84mm
Supported CPU	Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset	AMD B650
Audio	Realtek ALC4080 Codec 7.1-Channel High Performance Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel
Expansion Slots
PCI	2x PCI-E x16 slot Support x16/ x4 1x PCI-E x1 slot PCI_E1 PCIe 4.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset)
Memory Specifications
Maximum Memory	128GB
Slots	4x DIMM
Supported Memory	Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Type	DDR5
Graphics Specifications
Graphics	1x HDMI 1x DisplayPort Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, maximum resolution of 8K 60Hz
Max Shared Memory	16GB
Connector & Ports
Audio	HD Audio Connectors
Display Port	1 x DisplayPort
HDMI	1x HDMI
Internal I/O Ports	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C
LAN Port (s)	Realtek RTL8125BG 2.5Gbps LAN
RAID	Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Supported Storage	2x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 6x SATA 6G port
TPM (Trusted Platform Module )	1x TPM pin header(Support TPM 2.0)
USB (s)	4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear)
Wireless Communication module	AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2
Warranty Information
Warranty	3 years

Description

MSI MAG B650M MORTAR WIFI AM5 M-ATX Motherboard Price in Bangladesh

The MSI MAG B650M MORTAR WIFI AM5 M-ATX Motherboard is a high-performance, compact motherboard designed for gamers, streamers, and professionals who need powerful features in a smaller form factor. Built on the AMD B650 chipset with support for AMD Ryzen 9000, 8000, and 7000 Series processors, it delivers future-ready performance with DDR5 memory, PCIe 4.0 lanes, dual M.2 storage, and advanced connectivity including Wi-Fi 6E and 2.5Gb LAN. With military-grade durability and premium cooling support, this motherboard ensures long-lasting stability, smooth multitasking, and next-level gaming performance.

Key Features of MSI MAG B650M MORTAR WIFI AM5

AM5 Socket Compatibility

Supports AMD Ryzen 9000, 8000, and 7000 Series processors, offering next-generation performance for gaming, rendering, and multitasking.

AMD B650 Chipset Performance

Optimized for stability and overclocking, the B650 chipset ensures reliable system performance and faster data throughput.

DDR5 Memory Support

Equipped with four DIMM slots supporting up to 128GB DDR5 RAM with speeds up to 6400+ MHz (OC), delivering faster load times and multitasking efficiency.

PCIe 4.0 Expansion

Dual PCI-E x16 slots provide maximum bandwidth for the latest GPUs and add-in cards, boosting both gaming and productivity workloads.

Dual M.2 PCIe 4.0 Slots

Features two M.2 slots with PCIe 4.0 x4 interface for ultra-fast NVMe SSDs, enabling quick boot times and faster application loading.

Wireless and Wired Connectivity

Comes with Wi-Fi 6E for high-speed wireless networking and 2.5Gbps LAN for stable wired connections.

7.1 Channel HD Audio

Integrated Realtek ALC4080 delivers crystal-clear audio with support for high-resolution playback and immersive gaming sound.

USB Connectivity

Offers USB 3.2 Gen2x2 Type-C along with multiple high-speed USB ports on both front and rear panels for easy device integration.

Cooling and RGB Sync

Includes headers for CPU, pump, and chassis fans, along with ARGB sync support for customized lighting setups.

Why Choose the MSI MAG B650M MORTAR WIFI AM5?

Compact micro-ATX design with premium features
Balanced performance and durability
Future-ready with DDR5, PCIe 4.0, Wi-Fi 6E, and 2.5G LAN
Built with military-grade components for stability
Ideal for gaming PCs, creative builds, and professional setups

MSI MAG B650M MORTAR WIFI Reveiw

FAQ

Q1: Which processors are supported by the MSI MAG B650M MORTAR WIFI AM5?
It supports AMD Ryzen 9000, 8000, and 7000 Series processors on the AM5 socket.

Q2: Does it support DDR4 RAM?
No, it only supports DDR5 memory for faster speeds and improved efficiency.

Q3: How many M.2 slots are available?
It comes with two M.2 PCIe 4.0 x4 slots for NVMe SSDs.

Q4: Is Wi-Fi built-in?
Yes, it includes built-in Wi-Fi 6E and Bluetooth 5.3.

Q5: What form factor is this motherboard?
It is a Micro-ATX (M-ATX) motherboard, suitable for mid-tower and compact builds.
