GIGABYTE A520M K V2 AM4 Micro ATX Motherboard
GIGABYTE A520M K V2 AM4 Micro ATX Motherboard
GIGABYTE A520M K V2 AM4 Micro ATX Motherboard
-11 %
GIGABYTE A520M K V2 AM4 Micro ATX Motherboard
GIGABYTE A520M K V2 AM4 Micro ATX Motherboard
GIGABYTE A520M K V2 AM4 Micro ATX Motherboard

GIGABYTE A520M K V2 AM4 Micro ATX Motherboard

  • Offer Price: 7,700৳
  • Price: 8,700৳
  • Stock: In Stock
  • Brand: Gigabyte
  • Model: A520M K V2
  • Product Code: 884934
7,700৳
8,700৳
Ex Tax: 7,700৳

Key Features

  • Support: Ryzen 5000/ 5000G/4000G/ 3000/3000G Series
  • Supported RAM: 2 x DDR4, up to 64GB, 5100(O.C.)
  • Graphics Output: 1 x HDMI, 1x D-Sub
  • Features: 1 x M.2 Slot, Realtek GbE LAN

For further queries, please call 01958-013555

Specification

Basic Information
BIOS 1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 23.3cm x 19.8cm
Supported CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Chipset AMD A520
Audio Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Expansion Slots
M.2 Socket 1 x M.2 connector
PCI CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Memory Specifications
Maximum Memory 64 GB (32 GB single DIMM capacity)
Slots 2 xDIMM
Supported Memory Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Type DDR4
Graphics Specifications
Graphics Integrated Graphics Processor:
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Support for HDMI 2.0 version and HDCP 2.2.
Max Shared Memory 16 GB
Connector & Ports
HDMI 1 x HDMI
Internal I/O Ports 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x speaker header
1 x Clear CMOS jumper
1 x chassis intrusion header
LAN Port (s) Realtek GbE LAN chip (1 Gbps/ 100 Mbps)
RAID Support for RAID 0, RAID 1, and RAID 10
Supported Storage CPU:
1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support)
Chipset:
4 x SATA 6Gb/s connectors
TPM (Trusted Platform Module ) 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
USB (s) CPU:
4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
2 x USB 3.2 Gen 1 ports available through the internal USB header
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Others
Bundled Software Norton Internet Security (OEM version)
LAN bandwidth management software
Special Features Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS
EasyTune
Smart Backup
System Information Viewer
Support for Q-Flash
Support for Xpress Install
Warranty Information
Manufacturing Warranty 3 years

Description

GIGABYTE A520M K V2 AM4 Micro ATX Motherboard

The GIGABYTE A520M K V2 AM4 Micro ATX Motherboard is a reliable and budget-friendly motherboard designed for modern AMD Ryzen processors. Built with the efficient AMD A520 chipset, this motherboard delivers stable performance, efficient power delivery, and essential connectivity for everyday computing, office tasks, and entry-level gaming systems.

Designed in a Micro ATX form factor, the GIGABYTE A520M K V2 fits easily into compact PC cases while still offering important expansion options. It supports AMD Ryzen 3000, 4000 G-Series, and 5000 Series processors on the AM4 socket, making it a great foundation for building a cost-effective yet powerful desktop PC.

The motherboard also includes M.2 NVMe storage support, allowing users to install high-speed SSDs for faster boot times and improved system responsiveness. Combined with multiple USB ports, PCIe expansion slots, and high-quality Gigabyte components, this motherboard ensures dependable performance for both work and entertainment.

With Gigabyte’s Ultra Durable design, efficient thermal management, and an easy-to-use BIOS interface, the A520M K V2 provides stability and convenience for system builders. Whether you are assembling a home PC, office workstation, or entry-level gaming rig, this motherboard offers the essential features needed for smooth and reliable computing.


Key Features of GIGABYTE A520M K V2 Motherboard

  • Supports AMD Ryzen ProcessorsCompatible with AMD Ryzen 3000, 4000 G-Series, and 5000 Series processors on the AM4 socket for reliable and efficient performance.
  • AMD A520 Chipset: The A520 chipset provides stable operation and optimized compatibility for modern Ryzen CPUs without unnecessary complexity.
  • High-Speed M.2 NVMe Storage: Equipped with an M.2 slot supporting NVMe SSDs, enabling faster data transfer speeds and improved system responsiveness.
  • Micro ATX Form Factor: Compact design that fits in most PC cases while still offering essential connectivity and expansion options.
  • Multiple Connectivity Options: Includes USB ports, HDMI output, PCIe slots, and SATA connectors for flexible system configuration.
  • Durable Build Quality: Built with Gigabyte’s Ultra Durable components to ensure long-term reliability and stable performance.
  • User-Friendly BIOS: An intuitive BIOS interface makes system configuration and hardware management easy for both beginners and experienced builders.

GIGABYTE A520M K V2 Motherboard Price in Bangladesh

The GIGABYTE A520M K V2 AM4 Micro ATX Motherboard is available in Bangladesh at an affordable price, making it an excellent option for budget PC builders and office users. Prices may vary depending on stock availability and promotions.

You can buy the original GIGABYTE A520M K V2 Motherboard from Canvas IT to ensure product authenticity, competitive pricing, and reliable customer support.

Why Choose the GIGABYTE A520M K V2 Motherboard

The GIGABYTE A520M K V2 is designed to provide a balance of performance, stability, and affordability. Its compatibility with modern AMD Ryzen processors, support for fast NVMe storage, and durable construction make it a dependable choice for various PC builds.

This motherboard is particularly suitable for users who need a stable platform for office work, everyday computing, or entry-level gaming without spending extra on high-end features that may not be necessary.

GIGABYTE A520M K V2 Review

Buy GIGABYTE A520M K V2 Motherboard from Canvas IT

You can purchase the original GIGABYTE A520M K V2 Motherboard from Canvas IT with confidence. Canvas IT provides authentic products, competitive prices, and reliable customer service. Customers in Dhaka, Chattogram, and all over Bangladesh can easily order this motherboard and enjoy convenient nationwide delivery.

If the GIGABYTE A520M K V2 is not available or you want to explore similar options, Canvas IT also offers several alternative AM4 motherboards that provide comparable performance and features, such as:

  1. GIGABYTE A520M S2H Motherboard
  2. GIGABYTE B450M DS3H Motherboard
  3. ASUS PRIME A520M-K Motherboard

FAQs

Does the GIGABYTE A520M K V2 support Ryzen 5000 series processors?

Yes, this motherboard supports AMD Ryzen 5000 Series processors with the AM4 socket.

Does it have an M.2 slot for SSD?

Yes, the motherboard includes an M.2 slot that supports high-speed NVMe SSD storage.

Is this motherboard good for gaming?

Yes, it is suitable for entry-level gaming builds when paired with a compatible Ryzen processor and a dedicated graphics card.

What form factor is the GIGABYTE A520M K V2?

It uses a Micro ATX form factor, which fits most standard PC cases.

Where can I buy the GIGABYTE A520M K V2 in Bangladesh?

You can purchase the original motherboard from Canvas IT at a competitive price.
