Asus TUF GAMING A520M-PLUS II AMD AM4 microATX Motherboard

-14 %

Asus TUF GAMING A520M-PLUS II AMD AM4 microATX Motherboard

Offer Price: 12,500৳
Price: 14,500৳
Stock: In Stock
Brand: Asus
Model: TUF GAMING A520M-PLUS II
Product Code: 846232

Based on 0 reviews. - Write a review

12,500৳

14,500৳

Ex Tax: 12,500৳

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supported CPU: Ryzen 5000/ 4000 G/ 3000 Series
Supported RAM: 4 x DIMM, Max. 128GB, DDR4
Graphics Output: 1 x DisplayPort 1.2, 1 x HDMI 2.1, 1 x D-Sub
Features: Onboard RGB headers

View more details

For further queries, please call 01999-913558

Specification

Basic Information
BIOS	128 Mb Flash ROM, UEFI AMI BIOS
Form Factor	microATX 24.4cm x 24.4cm
Supported CPU	AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
Chipset	A520
Audio	Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback" Audio Features - Audio Shielding - Premium Japanese audio capacitors - Dedicated audio PCB layers *A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Expansion Slots
PCI	AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors 1 x PCIe 3.0 x16 slot (supports x16 mode) AMD A520 Chipset 2 x PCIe 3.0 x1 slots
Memory Specifications
Maximum Memory	128GB
Slots	4 x DIMM
Supported Memory	4866(OC)/ 4800(OC)/ 4600(OC)/ 4466(OC)/ 4400(OC)/ 4266(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3333(OC)/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133 MHz, Un-buffered Memory Dual Channel Memory Architecture
Type	DDR4
Graphics Specifications
Graphics	1 x DisplayPort 1.2 1 x HDMI 2.1(4K@60Hz) 1 x D-Sub
Connector & Ports
Audio	3 x Audio jacks
Display Port	1 x DisplayPort
HDMI	1 x HDMI port
Internal I/O Ports	Fan and cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 2 x AURA Addressable Gen 2 header 2 x AURA RGB headers 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x 10-1 pin System Panel header
LAN Port (s)	1 x Realtek 1Gb Ethernet TUF LANGuard
Supported Storage	AMD Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) AMD A520 Chipset: 4 x SATA 6Gb/s ports Support RAID 0, 1, 10
TPM (Trusted Platform Module )	1 x SPI TPM header (14-1pin)
USB (s)	4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB:Total 6 ports 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 3 USB 2.0 ports
Others
Bundled Software	ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM Fan Xpert 2+ - EZ update - PC Cleaner - System Information TUF GAMING CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode
Special Features	ASUS TUF PROTECTION - DIGI+ VRM - ESD Guards - TUF LANGuard - Overvoltage Protection - SafeSlot Core+ - ASUS Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-Slot ASUS Thermal Solution - VRM heatsink design ASUS EZ DIY - BIOS FlashBack button - BIOS FlashBack LED AURA Sync - AURA RGB headers - Addressable Gen 2 RGB headers
Warranty Information
Manufacturing Warranty	3 Years

Description

Asus TUF GAMING A520M-PLUS II AMD AM4 microATX Motherboard

The Asus TUF GAMING A520M-PLUS II is a durable and performance-oriented AMD AM4 motherboard designed for gamers and PC builders who need long-lasting stability at an affordable cost. Powered by the reliable AMD A520 chipset, it supports Ryzen 5000, 4000 G-Series, and 3000 Series processors, making it ideal for entry-level to mid-range gaming builds in Bangladesh.

Engineered with TUF military-grade components, AI noise-cancelling tech, and optimized power design, this board ensures smooth performance during long gaming sessions or productivity workloads. Its advanced cooling architecture and reinforced build quality make it a dependable choice for users looking for the best Asus A520 motherboard price in Dhaka and across Bangladesh.

Whether you're building a budget gaming PC or upgrading your current setup, the Asus TUF GAMING A520M-PLUS II delivers the perfect balance of power, durability, and value.

Key Features

Supports Latest AMD Ryzen Processors:Compatible with Ryzen 5000, 4000 G-Series, and 3000 Series CPUs, ideal for gaming and productivity builds in Bangladesh.
TUF Military-Grade Components:Built with high-quality chokes, capacitors, and MOSFETs for long-term durability, especially in humid environments like Dhaka.
Enhanced Power Delivery:8-pin ProCool connector and optimized VRM ensure stable power for multi-core Ryzen processors.
Comprehensive Cooling:Features VRM heatsinks, Fan Xpert 2+, and multiple fan headers for improved thermal performance.
High-Speed Connectivity:Includes PCIe 3.0, M.2 slot, USB 3.2 Gen 1 ports, and Realtek Gigabit LAN for fast networking and storage.
Crystal-Clear Audio:TUF audio design with EMI shielding and high-quality capacitors for immersive gaming sound.
MicroATX Form Factor:Perfect for small and mid-size gaming PC builds, widely preferred in Bangladesh for compact setups.
Budget-Friendly Performance:One of the best-value AMD A520 motherboards for users searching for Asus A520M-PLUS II price in Bangladesh.

FAQs

1. What is the price of the Asus TUF GAMING A520M-PLUS II in Bangladesh?

Prices vary depending on the retailer, but it is known as one of the best budget TUF motherboards. For the most updated Asus A520M-PLUS II price in Bangladesh, check reliable PC hardware shops or online stores.

2. Is this motherboard good for gaming?

Yes. Paired with Ryzen 3, Ryzen 5, or even Ryzen 7 processors, it delivers excellent gaming performance for budget and mid-range builds.

3. Does it support overclocking?

No. The A520 chipset does not support CPU overclocking, but it supports memory overclocking.

4. Can I use it with Ryzen 5000 processors?

Yes, it fully supports Ryzen 5000 series CPUs, making it a great future-proof choice in Dhaka and across Bangladesh.

5. Does it have an M.2 slot?

Yes, it includes an M.2 slot for high-speed NVMe SSDs.

6. Is the motherboard suitable for small builds?

Yes. Its microATX design fits compact cases widely available in Bangladesh.
