ASUS Pro WS WRX90E-SAGE SE AMD sTR5 EEB Workstation Motherboard

-11 %

ASUS Pro WS WRX90E-SAGE SE AMD sTR5 EEB Workstation Motherboard

Offer Price: 290,000৳
Price: 327,390৳
Stock: In Stock
Brand: Asus
Model: Pro WS WRX90E-SAGE SE
Product Code: 908688

Based on 0 reviews. - Write a review

290,000৳

327,390৳

Ex Tax: 290,000৳

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supported CPU: Threadripper PRO 9000 & 7000 WX-Series (sTR5)
Supported RAM: 8x DIMM, DDR5, 8 Channel Memory Architecture
Storage: 4 x M.2, 2 x SlimSAS, 4 x SATA 6Gb/s
1 x Realtek 1Gb Ethernet, 1 x Intel dual 10Gb Ethernet

View more details

For further queries, please call 01999-913558

Specification

Basic Information
BIOS	256 Mb Flash ROM, UEFI AMI BIOS(text-based)
Form Factor	EEB Form Factor 12 inch x 13 inch (30.5 cm x 33 cm)
Supported CPU	AMD Socket sTR5 for Ryzen Threadripper PRO 9000 & 7000 WX-Series*
Chipset	AMD WRX90 Chipset
Audio	3 x Audio jacks
Generel information
USB	Rear USB (Total 9 ports) 2 x USB 40Gbps (USB4®) with ASMedia ASM4242 controller ports (2 x USB Type-C®) 6 x USB 10Gbps ports (6 x Type-A) 1 x USB 2.0 port (1 x Type-A ) Front USB (Total 7 ports) 1 x USB 20Gbpsconnector (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5G ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Memory Specifications
Maximum Memory	Max. 96GB
Slots	8 x DIMM
Type	DDR5
Graphics Specifications
Graphics	Supports 4K@60Hz as specified in HDMI 2.1.
Connector & Ports
Audio	Realtek ALC1220P Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback Audio Features - Premium audio capacitors - Dedicated audio PCB layers - Unique de-pop circuit
Display Port	1 x DisplayPort
HDMI	1x HDMI
Internal I/O Ports	Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x W_PUMP+ header 5 x 4-pin Chassis Fan headers 2 x 4-pin VRM Fan header (with VRM FAN onboard) 1 x 4-pin M.2 Fan header (with M.2 FAN onboard) Power related 1 x 24-pin Main Power connectors 2 x 8-pin +12V Power connectors 2 x 8-pin PCIe to CPU power connectors 2 x 8-pin PCIe Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports 2 x SlimSAS port USB 1 x USB 20Gbps connector supports USB Type-C® 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 1 x Chassis intrusion header 1 x COM port header 1 x FlexKey button 1 x Front panel audio header (F_AUDIO) 1 x LN2 mode jumper 1 x M.2 slot (Key E) 7 x ProbeIt measurement points 1 x ReTry button 1 x RSVD switch 1 x Slow mode switch 1 x Safe boot button 1 x SPI TPM header (14-1 pin) 1 x Start button 1 x 10-1 pin system panel header 1 x Thermal sensor header
LAN Port (s)	1 x Realtek 1Gb Ethernet (Dedicated management LAN for AST2600) 1 x Intel® dual 10Gb Ethernet
RAID	AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10.
Supported Storage	Total supports 4 x M.2 slots, 2 x SlimSAS ports and 4 x SATA 6Gb/s ports* AMD Ryzen™ Threadripper™ PRO 9000 & 7000 WX-Series Processors* M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD WRX90 Chipset 2 x SlimSAS slots support PCIe 4.0 x4 mode NVMe device 4 x SATA 6Gb/s ports
TPM (Trusted Platform Module )	1 x SPI TPM header (14-1 pin)
Others
Bundled Software	ASUS Exclusive Software Armoury Crate - Fan Xpert 4 ASUS CPU-Z Adobe Creative Cloud (Free Trial) Norton 360 for Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUSTeK. EzFlash Utility FlexKey IT Management software supported - ASUS Control Center Express(ACCE)
Special Features	ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design with SPS) - ESD Guards - LANGuard - Overvoltage protection - SafeSlot - Stainless-steel back I/O ASUS Q-Design - M.2 Q-Latch - Q-Release Slim (with PCIe SafeSlot) - Q-Code - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate and onboard thermal pads - M.2 heatsink - Steel backplate - VRM heatsink design with active fans ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Clear CMOS button - ProCool II - Pre-mounted I/O shield - SafeSlot - SafeDIMM Bespoke Motherboard Design & Business Focused Features - 24/7 Reliability - Overcurrent Protection BMC Related 1 x BMC switch 1 x BMC LAN fixed IP switch 1 x IPMI switch 1 x Message LED header 1 x microSD card socket 2 x LAN LED headers 1 x Location LED header 1 x Location button header 1 x PSU_SMB header 1 x SMART_PSU switch 1 x VGA switch 1 x VGA header (Dedicated Management for AST2600) 1 x VPP_I2C header
Warranty Information
Manufacturing Warranty	3 Years

Description

ASUS Pro WS WRX90E-SAGE SE AMD sTR5 EEB Workstation Motherboard Price in Bangladesh

The ASUS Pro WS WRX90E-SAGE SE is a high-end workstation motherboard designed for professionals who need exceptional processing power, expansion capability, and reliability. Built around the AMD WRX90 chipset and AMD sTR5 socket, this motherboard supports AMD Ryzen Threadripper PRO 9000 WX-Series and 7000 WX-Series processors, making it an excellent platform for AI, 3D rendering, simulation, engineering, scientific computing, and other demanding professional workloads.

With support for large-capacity DDR5 memory and multiple PCIe 5.0 slots, the ASUS Pro WS WRX90E-SAGE SE is built for powerful multi-GPU workstation configurations and high-speed storage. Its enterprise-focused networking, extensive I/O, advanced cooling, and workstation-grade reliability make it suitable for professional systems that require consistent performance.

Key Features

AMD WRX90 chipset
AMD sTR5 CPU socket
Supports AMD Ryzen Threadripper PRO 9000 WX-Series processors
Supports AMD Ryzen Threadripper PRO 7000 WX-Series processors
8 DDR5 DIMM slots
High-capacity memory support
6 PCIe 5.0 x16 slots
Additional PCIe 5.0 x16 slot operating at x8
4 M.2 slots with PCIe 5.0 NVMe support
2 SlimSAS connectors
4 SATA 6Gb/s ports
AMD RAIDXpert2 RAID support
PCIe and SATA RAID 0/1/5/10
2x USB4 Type-C ports with up to 40Gbps bandwidth
6x USB 10Gbps Type-A ports
Dual Intel 10Gb Ethernet ports
Realtek 1Gb Ethernet management LAN
Front USB 20Gbps Type-C support
Realtek ALC1220P audio codec
120 dB SNR playback
113 dB SNR recording
Active VRM cooling
M.2 heatsink backplates
ASUS 5X Protection III
Q-DIMM, Q-Slot, and BIOS FlashBack
EEB form factor
Designed for professional workstation applications

ASUS Pro WS WRX90E-SAGE SE Price in Bangladesh

The ASUS Pro WS WRX90E-SAGE SE price in Bangladesh depends on availability, warranty, and current market conditions. As a premium Threadripper PRO workstation motherboard, it is designed for high-performance professional systems rather than standard desktop PCs.

For the latest ASUS Pro WS WRX90E-SAGE SE price in BD, contact Canvas IT for current stock and pricing.

Buy ASUS Pro WS WRX90E-SAGE SE from Canvas IT

Buy the ASUS Pro WS WRX90E-SAGE SE Workstation Motherboard from Canvas IT with competitive dealer pricing and reliable warranty support. Canvas IT can also assist with selecting compatible Threadripper PRO processors, DDR5 memory, GPUs, storage, and other workstation components.

Special Offer

Competitive Dealer Price in Bangladesh
Genuine ASUS Product
Warranty Support
Workstation PC Build Assistance
Threadripper PRO Configuration Support
Professional GPU & Storage Selection
Special Pricing for Bulk Orders
Nationwide Delivery Available

Why Choose ASUS Pro WS WRX90E-SAGE SE?

The ASUS Pro WS WRX90E-SAGE SE is an excellent choice for professionals who need maximum workstation expansion and multi-threaded computing performance. Its multiple PCIe 5.0 x16 slots make it particularly suitable for multi-GPU systems, while its high-speed networking and PCIe 5.0 storage support provide fast data transfer and storage performance.

For AI development, 3D rendering, engineering simulation, scientific workloads, virtualization, and professional content creation, this motherboard provides a powerful foundation for an advanced workstation.

Where Can ASUS Pro WS WRX90E-SAGE SE Be Used?

AI and Machine Learning
Deep Learning Workstations
3D Rendering
Animation and VFX
CAD and Engineering
Scientific Computing
Simulation and Modeling
Professional Video Production
Data Science
High-Performance Computing
Multi-GPU Workstations
Enterprise Workstations

Alternative Workstation Motherboards

ASUS Pro WS TRX50-SAGE WiFi
ASUS Pro WS WRX80E-SAGE SE WIFI
ASUS Pro WS W790E-SAGE SE
ASUS Pro WS X870E-SAGE SE

FAQs

1. Which processors are supported by the ASUS Pro WS WRX90E-SAGE SE?

It supports AMD Ryzen Threadripper PRO 9000 WX-Series and 7000 WX-Series processors using the AMD sTR5 socket.

2. How many RAM slots does this motherboard have?

The motherboard features 8 DDR5 DIMM slots for high-capacity workstation memory configurations.

3. Does the ASUS Pro WS WRX90E-SAGE SE support multiple graphics cards?

Yes. It provides multiple PCIe 5.0 x16 slots, making it suitable for multi-GPU workstation configurations.

4. How many M.2 slots are available?

It features four M.2 slots supporting high-speed PCIe 5.0 NVMe SSDs.

5. Does it support 10Gb Ethernet?

Yes. The motherboard features dual Intel 10Gb Ethernet ports along with a dedicated Realtek 1Gb management LAN.

6. Does the motherboard support RAID?

Yes. AMD RAIDXpert2 technology supports PCIe and SATA RAID configurations including RAID 0, 1, 5, and 10.
