GIGABYTE Z790 GAMING X AX ATX Motherboard

-1 %

GIGABYTE Z790 GAMING X AX ATX Motherboard

Offer Price: 33,500৳
Price: 34,000৳
Stock: In Stock
Brand: Gigabyte
Model: Z790 GAMING X AX
Product Code: 845899

Based on 0 reviews. - Write a review

33,500৳

34,000৳

Ex Tax: 33,500৳

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supported CPU: 14th Gen, 13th Gen & 12th Gen Processors (LGA1700)
Supported RAM: 4 x DDR5 DIMMs, up to 7600(O.C.)
Graphics Output: 1 x HDMI, 1 x DisplayPort
Features: 2.5GbE LAN & Wi-Fi 6E 802.11ax

View more details

For further queries, please call 01958-013555

Specification

Basic Information
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Supported CPU	LGA1700 socket: Support for the 14th,13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU
Chipset	Intel Z790 Express Chipset
Audio	2 x audio jacks
Expansion Slots
PCI	CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2) Support for AMD CrossFire technology (PCIEX16 and PCIEX4)
Memory Specifications
Maximum Memory	128GB (32 GB single DIMM capacity)
Slots	4 x DIMM sockets
Supported Memory	Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Type	DDR5
Graphics Specifications
Graphics	Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 * Support for DisplayPort 1.2 version and HDCP 2.3
Connector & Ports
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 4 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x reset button 1 x Q-Flash Plus button 1 x Clear CMOS button 1 x reset jumper 1 x Clear CMOS jumper
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB) 6 x SATA 6Gb/s connectors
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
USB (s)	Chipset: 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2 support 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Others
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Manufacturing Warranty	3 years

Description

GIGABYTE Z790 GAMING X AX ATX Motherboard

The GIGABYTE Z790 GAMING X AX ATX Motherboard is a premium performance choice for gamers, streamers, and PC builders in Bangladesh. Built with the powerful Intel Z790 Express chipset, it supports Intel 14th, 13th & 12th Gen Core processors on the LGA1700 socket, delivering blazing-speed computing for high-end rigs.

With DDR5 memory support up to 7600MHz (OC), PCIe 5.0 GPU compatibility, and multiple PCIe 4.0 M.2 SSD slots, this board brings lightning-fast data performance for gaming, rendering, and heavy multitasking. Its Wi-Fi 6E and 2.5GbE LAN ensure outstanding online stability — perfect for gamers in Dhaka and across Bangladesh.

Enhanced cooling, rugged power architecture, and stylish RGB Fusion lighting make this motherboard a future-proof PC foundation for enthusiast builds.

Key Features

CPU Support Intel 14th / 13th / 12th Gen Core, Pentium Gold & Celeron (LGA1700)
Chipset Intel Z790 Express
Memory DDR5 Dual Channel, Up to 7600MHz (OC)
Graphics Slots PCIe 5.0 x16 for next-gen GPUs
Storage Multiple PCIe 4.0 M.2 NVMe SSD slots
Networking Intel Wi-Fi 6E + 2.5GbE Gaming LAN
USB Ports USB 3.2 Gen 2x2 Type-C, Fast Connectivity
Cooling Advanced Thermal Design with enlarged heatsinks
Audio Premium high-def gaming sound
Aesthetics RGB Fusion supports gaming build lighting

FAQs

Q1: Does it support Intel 14th Gen processors?

Yes — fully compatible out of the box.

Q2: What kind of RAM works with this motherboard?

High-speed DDR5 memory only.

Q3: Can it support PCIe 5.0 graphics cards?

Yes — ideal for the latest GPUs.

Q4: Does it include built-in Wi-Fi?

Yes — Wi-Fi 6E comes integrated for ultra-fast wireless.

Q5: What is the GIGABYTE Z790 GAMING X AX price in Dhaka?

Prices vary — I can help you check the latest price in Bangladesh if you want!
