GIGABYTE B450M DS3H WIFI AM4 AMD Micro ATX Motherboard

Stock: In Stock
Brand: Gigabyte
Model: B450M DS3H WiFi

Based on 0 reviews. - Write a review

12,200৳

13,400৳

Ex Tax: 12,200৳

Add to PC Builder

Key Features

Supported Processor: AMD Ryzen 5000/ 5000 G/ 3rd Gen / 2nd Gen / 1st Gen
Supported Memory: Dual Channel DDR4, 4 DIMMs
Intel Dual Band 802.11ac WIFI & BT 4.2
High Quality Audio Capacitors

View more details

For further queries, please call 01999-913558

Specification

Basic Information
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 21.5cm
Supported CPU	AM4 Socket: Supports AMD Ryzen 5000 series / Ryzen 5000 G-Series/ 3rd Gen Ryzen/ 2nd Gen Ryzen 1st Gen Ryzen/ 2nd Gen Ryzen with Radeon Vega Graphics/ 1st Gen Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors (Please refer "CPU Support List" for more information.)
Chipset	AMD B450
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out
Expansion Slots
PCI	1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 1 x PCI Express x16 slot, running at x1 (PCIEX1_2) 1 x PCI Express x1 slot (The PCIEX1_1 and PCIEX1_2 slots conform to PCI Express 2.0 standard.)
Memory Specifications
Maximum Memory	128 GB
Slots	4 x DDR4 DIMM sockets
Supported Memory	Support for DDR4 3600(O.C.)/3466(O.C.)/2933/2667/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.)
Type	Dual channel memory architecture
Graphics Specifications
Graphics	Radeon Vega Graphics/ 1st Gen Ryzen with Radeon Vega Graphics/ Athlon
Connector & Ports
HDMI	1 x HDMI port
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x CPU cooler LED strip/RGB LED strip header 1 x RGB LED strip header 2 x addressable LED strip headers 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x Clear CMOS jumper
LAN Port (s)	Realtek GbE LAN chip (10/100/1000 Mbit)
Supported Storage	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIex4/x2 SSD support) Actual support may vary by CPU. Supports only M.2 SATA SSDs when using an AMD Athlon™-series/ 7th Gen. A-series or Athlon X4 APU. 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 Refer to "1-7 Internal Connectors," for the installation notices for the M.2 connector.
TPM (Trusted Platform Module )	1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
USB (s)	CPU: 4 x USB 3.1 Gen 1 ports on the back panel Chipset: 2 x USB 3.1 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Others
Bundled Software	Norton Internet Security (OEM version) cFosSpeed
Special Features	Support for APP Center Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install
Warranty Information
Manufacturing Warranty	3 years

Description

GIGABYTE B450M DS3H WIFI AM4 AMD Micro ATX Motherboard

The GIGABYTE B450M DS3H WIFI AM4 AMD Micro ATX Motherboard is an excellent choice for users who want fast performance, strong connectivity, and dependable compatibility with AMD Ryzen processors. Supporting Ryzen 5000, 4000, and 3000 series CPUs, this motherboard delivers smooth multitasking and reliable power delivery for gaming, editing, or everyday use.

With dual-channel DDR4 memory support up to 128GB, built-in Wi-Fi and Bluetooth, and multiple display outputs, the B450M DS3H WIFI is a versatile option for compact PC builds. It also includes RGB Fusion lighting control, advanced cooling, NVMe support, and durable Ultra Durable components—making it ideal for budget-friendly gaming and productivity PCs.

If you're looking for the latest GIGABYTE B450M DS3H WIFI price in Bangladesh or the best offer in Dhaka, this motherboard offers excellent value for money.

Key Features

Powerful AM4 Processor Support

Compatible with AMD Ryzen 5000, 4000 G-Series, 3000 Series, and older Ryzen CPUs.
Ideal for gaming, content creation, and heavy multitasking.

Built-In Wi-Fi & Bluetooth

Features 802.11ac Wi-Fi and Bluetooth connectivity.
Perfect for users who want fast wireless internet without extra adapters.

Dual-Channel DDR4 Memory

Supports up to 128GB DDR4 RAM.
Delivers stable and high-speed performance for demanding applications.

High-Speed Storage Support

Equipped with NVMe M.2 slot for faster boot and load times.
Ideal for gaming and productivity builds.

Compact Micro ATX Design

Perfect for small gaming cases and office builds.
Offers balanced performance without taking up much space.

Multiple Display Outputs

Includes HDMI and DVI ports.
Supports multi-display setups in both home and office environments.

RGB Fusion Support

Customizable RGB lighting to match your PC build’s theme.

GIGABYTE Ultra Durable Build

High-quality components ensure long-lasting reliability and strong performance.

FAQs

1. What is the GIGABYTE B450M DS3H WIFI price in Bangladesh?

The GIGABYTE B450M DS3H WIFI price in Bangladesh varies depending on the retailer, stock availability, and ongoing offers. You can check updated prices from trusted computer stores in Dhaka and online shops across Bangladesh.

2. Is this motherboard good for gaming?

Yes, it supports Ryzen 5000 processors, NVMe SSDs, high-speed DDR4 RAM, and has built-in Wi-Fi—making it a great motherboard for budget and mid-range gaming.

3. Does the B450M DS3H WIFI support overclocking?

Yes, with a compatible Ryzen processor, overclocking is supported—but performance may vary depending on cooling and power supply quality.

4. Can I use this motherboard for video editing?

Absolutely. With support for multi-core Ryzen processors and high-capacity RAM, this board is perfectly suitable for editing, rendering, and professional workloads.

5. Does it support Wi-Fi out of the box?

Yes. It includes built-in Wi-Fi and Bluetooth, so you don’t need to purchase extra adapters.

6. Where can I buy this motherboard in Dhaka?

You can purchase the GIGABYTE B450M DS3H WIFI from major PC shops in Dhaka, Bashundhara City, Multiplan Center, and online tech retailers across Bangladesh.
